AMT Modular Vice 300

Scope of Application:-

•  Modular vices are widely used on milling machines, grinding machines, electro erosion machines and CNC machining centers.
• VMC Machine – for efficient precision machining.
• Horizontal installation – great variability, flexibility and rigidity.

Key Points :-

• Hardened, ground and polished guideway.
• Precision aligning holes in the ground and polished bottom surface.
• Robust base made of case-hardened steel.
• M8 thread for workpiece stopper.
• Pulldown jaws for rigid clamping.

Product Features :-

• No Wear
• Alloy steel body & Case-hardened at HRC 60 with Rigid construction and exclusion of vibrations
• Parallelism of body 0.02 mm.
• Machine vice with pull-down jaws.
• Since the workpiece is clamped by pulling down, floating up is prevented in spite of the powerful clamping force
• Reproducible clamping forces are achieved using a torque wrench
• 4 extra tapped holes over the jaws for special stack type jaw application

Prismatic Jaw :-

• Jaws for clamping round parts
• horizontal diameter 12-28 mm
• Vertical diameter 18-55 mm

Scope of Supply:-

• 1 X Vice
• 1 X Stopper
• 1 X L-Spanner
• 1 X Allen Key
• 2 X Tenon
• 4 X Side clamps
